Swagelok SS-45S8 40 Series Two-Way Ball Valve
The Swagelok SS-45S8 is a one-piece 316 stainless steel 40 Series two-way ball valve with 1/2 inch Swagelok tube fitting ends on both sides. The two-way straight pattern is engineered for on-off service in instrumentation, with a black lever handle, low-emissions certification, and packing that adjusts while the valve remains inline.
Key Features
- One-piece 316 stainless steel body for two-way straight (shutoff) flow
- PTFE-coated stainless steel seat
- PTFE packing with in-line packing adjustment
- 12 Cv with 0.406 in. (10.3 mm) orifice
- Black lever handle
- Low Emissions Certified (tested per WS-22)
Technical Specifications
- Part Number: SS-45S8
- Brand: Swagelok
- Type: Ball Valve (one-piece instrumentation, quarter-turn, 2-way shutoff)
- Body Material: 316 Stainless Steel (body)
- End Connections: 1/2 in. Swagelok tube fitting (both ends), 2-way straight/shutoff pattern
- Orifice: 0.406 in. (10.3 mm)
- Flow Coefficient (Cv): 12
- Working Pressure: 2500 psig @ 100 F (172 bar @ 37 C)
- Temperature Rating: -65 to 300 F (-53 to 148 C)
- Seat Material: PTFE-coated stainless steel
- Stem Packing: PTFE
- Handle: Lever handle (black)
