DK-LOK DMC-N-S Male Connector

The DK-LOK DMC-N is a male connector joining a DK-LOK twin-ferrule tube end to a male NPT tapered pipe thread (the -N sub-family designates NPT). The -S suffix is the 316/316L stainless steel build. It is one of the most common DK-LOK fittings, providing a gauge-able, leak-tight tube grip to a standard male pipe port.

Key Features

  • Twin (two) ferrule tube grip for leak-tight, gauge-able connection
  • Male NPT tapered pipe thread (N sub-family)
  • 316/316L stainless steel for superior corrosion resistance
  • Proven back-ferrule design grips across tube wall thickness and O.D.
  • Available in fractional and metric tube sizes
  • Can be ordered bored-through for thermocouple use (DMCT variant)

Technical Specifications

  • Brand: DK-LOK
  • Part Code: DMC-N-S
  • Type: Male Connector (NPT)
  • Material: 316/316L Stainless Steel
  • Design: Twin (two) ferrule compression
  • Connection 1: DK-LOK tube O.D.
  • Connection 2: Male NPT pipe thread
  • Spec Columns Published: Item #, Material, D – Tube O.D., T – Thread Size, E – Min., h – Width Across Flat, L, CAD
  • Tube Size Range: COMING SOON
  • Working Pressure: Governed by connecting tubing rating; pipe-end fittings rated to the lower-pressure port (e.g., SS316 1/2 in. tube = 4700 psi)
  • Temperature Rating: 316 SS material rated -425°F to 1200°F (-253°C to 649°C) per DK-LOK; final rating governed by the tubing and service – call for your application
  • Tube OD Range: 1/16 in. to 2 in. (fractional); 2 mm to 38 mm (metric)
  • Design Standard: Twin-ferrule fitting, tested to ASTM F1387
  • Working Pressure: Rated by tube size and wall thickness per the DK-LOK catalog. Call for quote.
SKU: DMC-N-S Categories: ,

Order Today from Collins-Oliver

Ready to get the leak-free reliability your system demands?

Contact Collins-Oliver for competitive pricing, same-day pickup in Baton Rouge.
