Swagelok SS-1GS4 1G Series Toggle Valve, 1/4 in.

Grab the SS-1GS4 when your operators need instant, one-motion shutoff they can work by feel. This 1G Series toggle valve flips open or closed with a single flick of its nylon handle, so you cut and restore flow fast on bleed, vent, and calibration lines. The straight-pattern 316 stainless steel body threads into your 1/4 in. Swagelok tube-fitting ends and delivers a leak-tight seal you can count on. A soft-seat PTFE stem tip gives you positive, bubble-tight shutoff on low-pressure service, and the compact footprint tucks neatly onto crowded instrument panels. Rate it to 300 psig from -20 to 200°F and mount it on analyzer racks, pneumatic controls, and sample-conditioning systems where quick manual actuation matters. You get 0.2 Cv through a 0.125 in. orifice, plenty for fast venting and purging without fuss. The bright toggle handle shows open or closed status at a glance, so your team never guesses. Want a panel-mount kit or angle-pattern version? Collins-Oliver stocks the 1G Series toggle build you need. Call for your quote.

Key Features

• One-motion toggle actuation for fast manual open-close
• 316 stainless steel straight-pattern body
• Soft-seat PTFE stem tip for bubble-tight low-pressure shutoff
• 0.2 Cv through a 0.125 in. (3.2 mm) orifice
• 300 psig rating, -20 to 200°F temperature range
• 1/4 in. Swagelok tube fitting ends with clear open-closed toggle handle

Technical Specifications

• Series: 1G Series (toggle valve)
• Body Material: 316 Stainless Steel
• Cv: 0.2
• Orifice: 0.125 in. (3.2 mm)
• End Connections: 1/4 in. Swagelok tube fitting (both ends)
• Working Pressure: 300 psig at 100°F (20.6 bar at 37°C)
• Temperature Range: -20 to 200°F (-28 to 93°C)
• Stem Tip: Soft-seat PTFE
• Flow Pattern: 2-way, straight
• Actuation: Manual nylon toggle handle
• Pricing: Call for quote
