Parker CPI Series Male Elbow, 1/4 in. Tube OD x 1/2 in. Male NPT, 316 Stainless Steel

Clearance disappears fast behind a gauge. The Parker 4-8 CBZ-SS gives you a 90 degree turn from 1/4 in. tube onto a 1/2 in. male NPT port, so you get the fitting out of the way of the next component instead of fighting for room.

Running 1/4 in. tube into a 1/2 in. pipe port normally means a bushing, and every bushing is one more threaded joint waiting to weep. This elbow does the size change and the direction change on a single 316 stainless body.

The CPI single-ferrule end seals metal to metal and remakes cleanly when you pull the instrument for calibration. Collins-Oliver stocks Parker CPI in Baton Rouge alongside 19,000 other part numbers. Call (800) 247-5756 and reach someone who knows the part.

Key Features

  • Stainless Steel AISI 316 construction
  • Sized for 1/4 in. tube outside diameter
  • End connection: 1/4 in. CPI single-ferrule compression tube fitting
  • Second end connection: 1/2 in. male pipe (NPT)
  • CPI™ Series (single ferrule compression fitting)
  • Genuine Parker product
  • In stock in Baton Rouge with same-day pickup and nationwide shipping

Technical Specifications

  • Part Number: 4-8 CBZ-SS
  • Manufacturer: Parker
  • Material: Stainless Steel AISI 316
  • Tube Outside Diameter: 1/4 in.
  • End Connection 1: 1/4 in. CPI single-ferrule compression tube fitting
  • End Connection 2: 1/2 in. male pipe (NPT)
  • Series: CPI™ Series (single ferrule compression fitting)
SKU: 4-8 CBZ-SS Categories: ,
