DK-LOK DTRM-N-S Male Run Tee

The DK-LOK DTRM is a male run tee with a male pipe thread on one end of the run and DK-LOK twin-ferrule tube ends on the remaining two legs (the opposite run end and the branch). The -N sub-family designates NPT thread and -S is the 316/316L stainless steel build. It places a male pipe port inline with the run while branching off to tube.

Key Features

Male thread on one run end, twin (two) ferrule tube on the other run end and branch
Male NPT tapered pipe thread (N sub-family)
316/316L stainless steel for superior corrosion resistance
Gauge-able, leak-tight back-ferrule design
Available in fractional and metric tube sizes
Published specs include thread size and across-flat dimensions

Technical Specifications

Brand: DK-LOK
Part Code: DTRM-N-S
Type: Male Run Tee (NPT)
Material: 316/316L Stainless Steel
Design: Twin (two) ferrule compression, run tee
Run Connection 1: Male NPT pipe thread
Run Connection 2: DK-LOK tube O.D.
Branch Connection: DK-LOK tube O.D.
Tube OD Range: Fractional tube O.D. from 1/16 in. with NPT run thread
Working Pressure: Governed by connecting tubing rating
Temperature Rating: 316 SS material rated -425°F to 1200°F (-253°C to 649°C) per DK-LOK; final rating governed by the tubing and service – call for your application
Tube OD Range: 1/16 in. to 2 in. (fractional); 2 mm to 38 mm (metric)
Design Standard: Twin-ferrule fitting, tested to ASTM F1387
Working Pressure: Rated by tube size and wall thickness per the DK-LOK catalog. Call for quote.
