DK-LOK DT Union Tee

The DK-LOK DT is a union tee that connects three lines of the same tube outside diameter in a tee configuration, all using gauge-able twin-ferrule tube ends. It is a tube-to-tube fitting offered in 316/316L stainless steel and brass across sizes from 1/16 inch to 2 inch O.D. The base DT code carries no material suffix, so material must be confirmed by the trailing code.

Key Features

Three twin (two) ferrule tube ends in a tee arrangement
Connects three equal-O.D. tube lines, branch at 90 degrees
Available in 316/316L stainless steel and brass
Tube sizes from 1/16 in. to 2 in. O.D. (138 catalog variations)
Gauge-able, leak-tight back-ferrule design
Offered in fractional and metric sizes

Technical Specifications

Brand: DK-LOK
Part Code: DT
Type: Union Tee
Material: 316/316L Stainless Steel (-S), Brass (-B), Carbon Steel (-C), Super Duplex (-SD), Alloy 20 (-L20) – set by suffix
Design: Twin (two) ferrule compression, tee
Connections: Three equal DK-LOK tube O.D. ends
Tube Size Range: 1/16 in. to 2 in. O.D.
Spec Columns Published: Item #, Material, D – Tube O.D., E – Min., h – Width Across Flat, H – Width Across Flat, l, L, CAD
Working Pressure: Governed by connecting tubing rating
Temperature Rating: 316 SS material rated -425°F to 1200°F (-253°C to 649°C) per DK-LOK; final rating governed by the tubing and service – call for your application
Tube OD Range: 1/16 in. to 2 in. (fractional); 2 mm to 38 mm (metric)
Design Standard: Twin-ferrule fitting, tested to ASTM F1387
Working Pressure: Rated by tube size and wall thickness per the DK-LOK catalog. Call for quote.
