DK-LOK DMCT-B Bored-Through Male Connector (Brass)
The DK-LOK DMCT is a bored-through male connector created by inserting 'T' into the DMC male connector part number, allowing a thermocouple, probe, or continuous tube to pass completely through the fitting body. The -B suffix indicates a brass body. It provides a gauge-able twin-ferrule grip and seal at any insertion depth along the through-bore.
Key Features
- Bored-through body for thermocouple/probe/continuous-tube pass-through
- Twin (two) ferrule grip seals at adjustable insertion depth
- Brass body construction
- Created from the DMC male connector by adding 'T' (e.g., DMCT8-8N-S)
- Male pipe thread on the port end
- Available in fractional and metric tube sizes
Technical Specifications
- Brand: DK-LOK
- Part Code: DMCT-B
- Type: Bored-Through Male Connector (Thermocouple)
- Material: Brass
- Design: Twin (two) ferrule compression, bored-through
- Connection 1: DK-LOK tube O.D. (through-bore)
- Connection 2: Male pipe thread
- Bore: Through-bored for thermocouple/probe insertion
- Tube Size Range: COMING SOON
- Working Pressure: Governed by connecting tubing rating
- Tube OD Range: 1/16 in. to 2 in. (fractional); 2 mm to 38 mm (metric)
- Design Standard: Twin-ferrule fitting, tested to ASTM F1387
- Working Pressure: Rated by tube size and wall thickness per the DK-LOK catalog. Call for quote.
